HIGH RIB (PBR) PROFILE PANEL
26ga Steel Painted Galvalume (also avaliable in 24ga)
SPIRCO manufactures the standard "PBR" steel panel for covering roofs and walls. The "PBR" panel has 1 1/4" deep major ribs spaced on 12" centers with two (2) minor ribs between each major rib. Each panel provides 36" (3'-0") of coverage.
(see picture above)
PBR stands for "Purlin Bearing Rib". It gives the panel added strength where it rests on the purlins. the roof panels shall be roll formed minimum A792 26 gauge steel with a minimum of 80 KSI yield strength. Wall panels will be a minimum of 80KSI. Unpainted panels shall be AZ55 Galvalume conforming to ASTM A792. Painted panels shall be AZ50 Galvalume with a 1.0 mil baked on enamel finish with the back of the panel having half (0.5) mil wash coat.
The colors above are not exact matches to the panels. You can call and request
a color sample or you can come to our city sales office
and have a look
